We take pride in being a reliable manufacturer and supplier of Aluminium 1050 Bars and Rods, celebrated for their remarkable resistance to corrosion, impressive thermal conductivity, and exceptional formability. Aluminium 1050 is a commercially pure grade, boasting 99.5% aluminium, which makes it one of the most stable and non-heat-treatable alloys out there. Our 1050 bars and rods are crafted with meticulous attention to dimensional accuracy and a superior surface finish, guaranteeing consistent performance across a variety of applications. Thanks to their lightweight, non-toxic nature, and excellent anodizing capabilities, Aluminium 1050 bars and rods find extensive use in chemical processing, food handling, architectural projects, and electrical applications.
Aluminium 1050 Bars and Rods generally consist of 99.5% aluminium, with just a hint of iron, silicon, copper, magnesium, manganese, and zinc. This alloy provides a tensile strength ranging from about 60 to 105 MPa and an elongation of 12 to 35%, depending on the temper. While it may not have the mechanical strength of heat-treatable alloys, it shines in terms of corrosion resistance in most environments. Aluminium 1050 also boasts high thermal and electrical conductivity, making it perfect for electrical conductors and heat exchangers. It’s highly workable, easily machinable, and ideal for cold forming, welding, and anodizing, which further boosts its surface durability and visual appeal.
| Bar Wire Standard | ASTM B221, B211, B565, B316, AMS 4121 2014 |
| Bar Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Round bar size | Diameter: 3-~800mm |
| Hex Bar size | 2-100mm A/F |
| Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Square bar size | 4 to 100mm |
| Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Rectangular Size | 33 x 30mm to 295 x 1066mm |
| Bars Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Bar Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Tempers | Tempers range from dead soft annealed to ultra spring temper |
| Rolled Flat Bars Condition | Hardened & tempered, annealed |
| Cold Rolled Bar Technique | Stainless Steel Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Rounds Bar Form | Round, Rod, T-Bar, Channel Bar, Precision Ground Bar, Flat Bar, Square, Blocks, Round Rod, Rings, Hollow, Triangle, Rectangle, Hex (A/F), Threaded, Half Round Bar, Profiles, Billet, Ingot, I/H Bar, Forging etc. |
| Grade | C | Mn | Si | Cu | Fe | Zn |
| 1050 | 0.05 max | 0.1 max | 0.30 max | 0-0.05 | 0-0.4 | 0-0.07 |
| UTS (Mpa) | Yield Strength (Mpa) | Elongation |
| 95 | 20 Min | 23 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS |
| EN AW-1050 A | 3.0255 | A91050 | S1B |
Aluminium 1050 Bars and Rods are utilized across a wide array of industries thanks to their versatility, corrosion resistance, and excellent formability. In the chemical and food sectors, they are the go-to choice for crafting storage tanks, piping, and food processing equipment due to their non-toxic properties. In the realm of electrical engineering, they serve as bus bars, conductors, and heat sinks because of their superior conductivity. Additionally, Aluminium 1050 is widely used in architectural cladding, signage, decorative trims, and roofing systems, making it a popular choice for both functionality and aesthetics.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
