Aiman Metals provides high-purity Aluminium 1060 Bars and Rods from its facility in Kuala Lumpur, Malaysia. Known for its excellent electrical and thermal conductivity, Aluminium 1060 is ideal for electrical, chemical, and food processing applications. We manufacture and supply 1060 bars and rods in custom sizes and finishes, ensuring superior formability, consistency, and quality. As a commercially pure aluminium alloy (99.6% min), 1060 is highly corrosion-resistant and lightweight, making it suitable for non-structural applications where conductivity and appearance matter.
Aluminium 1060 contains at least 99.6% pure aluminium, with trace elements of iron and silicon. It offers great electrical (approx. 54% IACS) and thermal conductivity, with tensile strength from 68–110 MPa. The alloy is non-heat-treatable but responds well to cold working for added strength. 1060 shows excellent corrosion resistance, workability, and is easy to weld. Its softness makes it best for applications requiring high formability and conductivity rather than structural strength.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Aluminium 1060 | Fe | Si | Mg | Mn | Cu | Zn | Ti | Al |
| 0.15 – 0.20 | 0.10 – 0.15 | 0.01 – 0.03 | 0.01 – 0.03 | 0.01 – 0.05 | 0.01 – 0.03 | 0.020 – 0.030 | 99.60 |
| Mechanical Properties – Al 1060 | |||||||||||||||||||
| Alloy | Temper | UTS(Mpa) | % Elongation | ||||||||||||||||
| Min | Max | 0.5 mm -0.8 mm | 0.81 mm – 1.30 mm | 1.30 mm – above | |||||||||||||||
| 1060 | O | 55 | 75 | 25 | 25 | 30 | |||||||||||||
| H12 | 75 | 110 | 6 | 6 | 7 | ||||||||||||||
| H14 | 90 | 120 | 5 | 5 | 6 | ||||||||||||||
| H16 | 95 | 130 | 4 | 4 | 4 | ||||||||||||||
| H18 | 130 | — | 3 | 3 | 3 | ||||||||||||||
| STANDARD | UNS | DIN |
| Aluminium 1060 | A91060 | – |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 1060 bars are corrosion-resistant. Due to its high purity, this alloy naturally forms a protective oxide layer on its surface, which helps resist corrosion from moisture and environmental factors.
Yes, Aluminium 1060 rods can be customized in size and length. Manufacturers typically offer customization to meet specific requirements for various industrial applications, ensuring precise dimensions and optimal performance.
Yes, Aluminium 1060 bars can be recycled after use. Aluminium is highly recyclable without losing its properties, making it an eco-friendly material that can be reused multiple times in various applications.
Aluminium 1060 Bars and Rods are widely used in electrical conductors, power transmission lines, and transformer windings due to their superior conductivity. They are also suitable for food-grade equipment, cookware, signage, nameplates, and reflective surfaces. In industrial settings, 1060 is utilized for chemical processing equipment, cleanroom parts, and light-duty structural elements. Its non-toxic, non-magnetic, and corrosion-resistant properties make it valuable in pharmaceuticals and food industries, as well as in architectural cladding and heat sinks.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
