Aiman Metals provides high-performance Aluminium 2024 Forgings in Kuala Lumpur, Malaysia—suitable for aerospace and structural applications where strength and fatigue resistance are essential. Being a copper-based aluminium alloy, 2024 is renowned for its superior mechanical strength and machinability. Although less corrosion-resistant than other grades, its stress performance renders it a favorite choice in demanding conditions. Aiman Metals manufactures precision-forged 2024 parts in different forms and specifications to ensure that they operate at their best and meet aerospace-grade quality standards.
Aluminium 2024 contains copper (3.8–4.9%), magnesium (1.2–1.8%), and manganese (0.3–0.9%). In T4 and T6 tempers, it provides tensile strength to ≈470 MPa. It is heat-treatable and possesses good fatigue strength and machinability, though it needs surface protection as it has lower corrosion resistance. Parts made from forged 2024 maintain superior strength even in severe load-bearing applications.
Standards : ASTM B247, B247
Temper : T6 T651 T6511
Specification : DIN, ASTM, BS and all International Standards
Flat bar blocks : up to 27″ width and 15,000 lbs.
Cylinders and sleeves : up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs : up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings : up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts : up to 144″ maximum length and 20,000 lbs.
| Grade | Al | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Other |
| min. | Bal | 3.80 | 0.30 | 1.20 | ||||||
| max. | Bal | 0.50 | 0.50 | 4.90 | 0.90 | 1.80 | 0.10 | 0.25 | 0.15 | 0.05 |
| Temper | Tensile Strength | Yield Strength | Elongation |
| KSI | KSI | % | |
| (annealed) | 32 | 14 | 12 |
| T3 | 63 | 42 | 15 |
| European Standard | OLD | WNr | UNS | ISO | USA (AA) | GERMANY (DIN) |
| AW-AlCu4Mg1 | AU4G1 | 3.1355 | A92024 | AlCu4Mg1 | 2024 | AlCuMg2 |
Yes, Aluminum 2024 is commonly used in precision forging applications due to its high strength, good fatigue resistance, and excellent machinability, making it suitable for aerospace and high-performance components.
Aluminum 2024 offers high strength, excellent fatigue resistance, good machinability, and superior corrosion resistance, making it ideal for custom forgings in aerospace, military, and high-performance applications.
Aluminium 2024 Forgings find extensive application in aerospace parts like wing spars, fuselage structures, and gear assemblies. It‘s also employed in high-performance car parts, robotics, and military equipment where strength and accuracy are vital. Other applications are tools, fasteners, and bearing components of machinery. The fatigue resistance and machinability of the alloy make it suitable for components that undergo repetitive stress and high mechanical loads.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
