Aiman Metals distributes high-strength Aluminium 2024 T3511 Bars and Rods in Kuala Lumpur, Malaysia, to aerospace, defense, and structural requirements. 2024 is a copper-based aluminum alloy with superior fatigue resistance and tensile strength. The T3511 temper produces stress-relieved, stretched material with enhanced toughness and dimensional stability. Aiman Metals supplies these rods and bars in diversified lengths and sizes, carefully machined to aerospace-grade specification tolerances. 2024 T3511 can be used for critical parts experiencing cyclic loading, high-impact loading, and harsh environments, qualifying it as a reliable material in stringent engineering applications.
Aluminium 2024 has 3.8–4.9% copper, 1.2–1.8% magnesium, and 0.3–0.9% manganese. It has tensile strength of ~470 MPa, yield strength ~325 MPa, and good resistance to fatigue in T3511 temper. It has poor corrosion resistance but good machinability and high fracture toughness. The alloy is solution heat-treated, stress relieved, and naturally aged, having good dimensional stability and resistance to crack under stress. 2024 T3511 cannot be welded by standard techniques but can be mechanically assembled. It is light in weight and very reliable under dynamic loading.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Grade | Al | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Other |
| min. | Bal | 3.80 | 0.30 | 1.20 | ||||||
| max. | Bal | 0.50 | 0.50 | 4.90 | 0.90 | 1.80 | 0.10 | 0.25 | 0.15 | 0.05 |
| Temper | Tensile Strength | Yield Strength | Elongation |
| KSI | KSI | % | |
| (annealed) | 32 | 14 | 12 |
| T3 | 63 | 42 | 15 |
| STANDARD | UNS | WERKSTOFF NR. |
| Aluminium 2024 T3511 | A92024 | 3.1355 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Aluminium 2024 T3511 is generally not recommended for welding due to its susceptibility to cracking and reduced strength after welding. However, specialized techniques like TIG welding and using filler materials can be employed with caution.
Yes, Aluminium 2024 T3511 bars are recyclable. Aluminium is highly recyclable without losing quality, making it an eco-friendly material for sustainable manufacturing and reducing environmental impact.
Aluminium 2024 T3511 is prone to corrosion, particularly in harsh environments with high humidity or exposure to saltwater. It is highly susceptible to pitting and stress corrosion cracking, though protective coatings can help mitigate this.
Aluminium 2024 T3511 Bars and Rods find extensive applications in aerospace structures, aircraft wing and fuselage, truck and trailer parts, and precision military equipment. They are also employed in structural bridges, roller coaster components, and robot arms where strength-to-weight ratio is very important. The alloy is well suited for sports equipment applications with high performance, racing components, and tooling parts. 2024 T3511 is often specified in engineering designs where there is a need for predictable fatigue life as well as dimensional consistency. It also finds application in landing gear, fuel tanks, missile systems, and other safety-related aerospace and transport components.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
