Aiman Metals stands out as a trusted manufacturer and supplier of Carbon Steel Bars and Rods right in the heart of Kuala Lumpur, Malaysia. They provide reliable steel solutions for a variety of industries, including construction, automotive, heavy equipment, manufacturing, and general engineering. Carbon steel is a popular choice thanks to its strength, versatility, and cost-effectiveness. Aiman Metals offers an extensive selection of carbon steel bars and rods in various grades and dimensions, featuring round, square, flat, and hex profiles. With a commitment to consistent quality, precise tolerances, and timely delivery, Aiman Metals caters to the diverse needs of clients looking for robust and machinable steel components.
Typically, Carbon Steel Bars and Rods have a carbon content that ranges from 0.15% to 0.60%, along with added manganese and trace elements. Depending on the specific grade, these materials can provide tensile strengths between 400–800 MPa, along with impressive hardness, ductility, and wear resistance. Low carbon grades are particularly easy to weld and shape, while medium and high carbon steels can be heat-treated to boost their mechanical performance. The machinability and affordability of carbon steel make it an excellent choice for both high-volume production and custom fabrication.
| Carbon Steel Bar Standard | ASTM A36, AMS 5513, AMS 5511, AMS 5647 |
|---|---|
| Carbon Steel Bar Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Carbon Steel Round bar size | Diameter: 3-~800mm |
| Carbon Steel Hex Bar size | 2-100mm A/F |
| CS Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Carbon Steel Square bar size | 4 to 100mm |
| Carbon Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Carbon Rectangular Bars Section | 3.0 to 12.0mm thickness |
| Carbon Steel Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| ASTM A36 Type Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| CS Threaded Bar Billet Size | 1/2 to 495mm Diameter |
| Carbon Steel Rectangular Size | 33 x 30mm to 295 x 1066mm |
| Carbon Hex Bars Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| ASTM A36 Type Hollow Bar Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Carbon T-Bar Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Rolled Carbon Steel Flat Bars Condition | Hardened & tempered, annealed |
| ASTM A36 Type Cold Rolled Bar Technique | Carbon Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| CS Rod Processing | Bar cutting to 650mm |
| Carbon Rounds Bar Form | Round, Rod, T-Bar, Channel Bar, Precision Ground Bar, Flat Bar, Square, Blocks, Round Rod, Rings, Hollow, Triangle, Rectangle, Hex (A/F), Threaded, Half Round Bar, Profiles, Billet, Ingot, I/H Bar, Forging etc. |
| Our Carbon Steel Round bar conforms to NACE MR0175/ISO 15156 | |
| Grades | Silicon | Mangenese | Carbon | Phosphorus. | Sulfur. |
|---|---|---|---|---|---|
| En-8D | 0.05/0.35 | 0.70/0.90 | 0.40/0.45 | 0.06 | 0.06 |
| En-9 | 0.50/0.80 | 0.50/0.60 | |||
| SAE 1006 | 0.10/0.30 | 0.25/0.40 | 0.08 max | 0.04 | 0.05 |
| SAE 1008 | 0.30/0.50 | 0.10 max | |||
| SAE 1030 | 0.10/0.40 | 0.60/0.90 | 0.28/0.34 | ||
| SAE 1035 | 0.32/0.38 | ||||
| SAE 1040 | 0.37/0.44 | ||||
| SAE 1010 | 0.10/0.30 | 0.30/0.60 | 0.08/0.13 | ||
| SAE 1018 | 0.60/0.90 | 0.15/0.20 | |||
| SAE 1020 | 0.30/0.60 | 0.18/0.23 | 0.09 | ||
| SAE 1045 | 0.10/0.40 | 0.60/0.90 | 0.40/0.50 | 0.05 | |
| Ck 45 | 0.15/0.35 | 0.50/0.80 | 0.42/0.50 | 0.04 | |
| Ck 55 | 0.60/0.90 | 0.52/0.60 | |||
| Ck 60 | 0.57/0.65 |
| Tensile Strength | Yield Stress, Min, MPa | % Elongation at gauge length 5.65 √Ѕo | Bend Test | ||
| Min, Mpa | |||||
| mm | <20 | 20-40 mm | >40 | min | min |
| mm | mm | ||||
| 410 | 250 | 240 | 230 | 23 | 3t* (*t is 3 times thickness) |
| EN | Normalized | ASTM | AMS | UNS |
|---|---|---|---|---|
| EN 1.0460 | A105n/SA 105n | ASTM A105 | ASME SA 105 | K03504 |
You’ll find Carbon Steel Bars and Rods in a wide array of applications, including shafts, bolts, axles, fasteners, structural supports, frames, and machine parts. In the construction industry, they play a crucial role in reinforcement and foundation systems. The automotive and heavy machinery sectors rely on them for load-bearing components due to their durability and strength. With their availability in various shapes and sizes, along with their compatibility with machining, welding, and forging processes, carbon steel bars and rods are truly essential materials in industrial manufacturing.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
