Aiman Metals, Kuala Lumpur, Malaysia, is one of the most prominent manufacturers and suppliers of premium metal products with a reputation for merging experience and innovation to cater to numerous industries. Among our best-selling products, Duplex Steel S31803 Forgings are unique for their exceptional mechanical properties, superior corrosion resistance, and consistent performance in extreme conditions. Manufactured to adhere to strict industry requirements, these forgings are very well suited for applications that require maximum attention in the oil and gas, chemical, marine, and power generation industries. For each product at Aiman Metals, precision manufacturing is ensured for durability, reliability, and long-lasting performance in rigorous operations.
Duplex Steel S31803 Forgings consist of 22% chromium, 5% nickel, 3% molybdenum, and approximately 0.2% nitrogen, with iron being the remainder. This alloy ensures high corrosion resistance, especially in environments with high chloride levels. The alloy has tensile strength of about 620 MPa (90 ksi) and yield strength of about 450 MPa (65 ksi), marrying strength with toughness. It also possesses high resistance to low-temperature impact resistance, pitting, crevice corrosion, and stress corrosion cracking. Moreover, Duplex S31803 is weldable and formable to a satisfactory degree, such that it is easily used for industrial purposes.
| Specifications | ASTM A182, ASME SA182 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S31803 | 0.030 max | 2.00 max | 1.00 max | 0.030 max | 0.020 max | 22.0 – 23.0 | 3.0 – 3.5 | 4.50 – 6.50 | 0.14 – 0.20 | 63.72 min |
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| S31803 | 7.805 | 0.285 | 1420 – 1465 | 2588 – 2669 |
| STANDARD | WERKSTOFF NR. | UNS |
| Duplex Steel S31803 | 1.4462 | S31803 |
The maximum operating temperature for Duplex Steel S31803 forgings is typically around 300°C (572°F). Beyond this temperature, the material may experience reduced strength and susceptibility to stress corrosion cracking.
Duplex Steel S31803 forgings are available in various sizes, including diameters ranging from 10 mm to 800 mm, and shapes like round, square, billets, blocks, and custom configurations, based on application needs.
Yes, S31803 Duplex Steel forgings are highly resistant to corrosion, especially in chloride-rich environments. They offer excellent protection against pitting, crevice, and stress corrosion cracking, making them ideal for harsh industrial applications.
Duplex Steel S31803 Forgings find extensive usage in industries requiring strength, durability, and corrosion resistance. In the oil and gas sector, they are utilized in pipelines, subsea hardware, and pressure vessels operating in chloride and high-pressure environments. They are used in the chemical industry in pumps, valves, reactors, and heat exchangers where reliability under aggressive conditions is needed. Marine and desalination plants use them for seawater applications, shafts, and structural parts because of their pitting and crevice corrosion resistance. S31803 forgings’ high mechanical strength and resistance to harsh conditions make them imperative for long-term, reliable performance in demanding applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
