Aiman Metals, a leading company based in Kuala Lumpur, Malaysia, is a well-known manufacturer and supplier of high-quality metal products designed for high-performance sectors. In our wide range of products, Hastelloy C22 Bars and Rods are among the most demanded materials because of their excellent corrosion resistance, durability, and strength. Renowned for its performance in harsh and aggressive applications, Hastelloy C22 is well suited for applications in chemical processing, petrochemical, pollution control, and marine. With precision engineering, rigorous adherence to international standards, and prompt delivery, Aiman Metals is a reliable partner for customers around the world who require reliability and performance.
Hastelloy C22 Rods and Bars are nickel-based alloys containing around 56–60% nickel, 20–22% chromium, and 12–15% molybdenum, with trace amounts of tungsten, cobalt, and iron. This new chemical composition delivers superior resistance against pitting, crevice corrosion, and stress corrosion cracking, even in the presence of acids and chlorides. Hastelloy C22 is mechanically very strong in tensile strength, having superior weldability, and resistance to temperatures up to 1500°F (815°C). Its corrosion resistance and strength in both reducing and oxidizing conditions make it a viable alloy, providing outstanding performance at low maintenance in severe applications.
| Standard | ASTM B574, ASME SB574 |
| Round Bar Size | 3mm~ 800mm |
| Square Bar Size | 4mm* 4mm ~100mm* 100mm |
| Flat Bar Size | 2mm ~ 100mm |
| Hex Bar Size | 2mm ~ 100mm |
| Angle Size | 3mm* 20mm* 20mm~ 12mm* 100mm* 100mm |
| Thickness | 50 mm to 6000 mm Long |
| Length | 1 To 6 Meters, Custom Cut Length |
| Form | Round, Square, Hex(A/F), Rectangle, Billet, Ingot, Forging Etc |
| Grade | Ni | C | Cr | Co | Fe | Mn | Mo | P | Si | S | W | V |
| Hastelloy C22 | Bal | 0.010 max | 20 – 22.5 | 2.5 max | 2 – 6 | 0.50 max | 12.5 – 14.5 | 0.02 max | 0.08 max | 0.02 max | 2.5 – 3.5 | 0.35 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 1,00,000 , MPa – 690 | Psi – 45000 , MPa – 310 | 45 % |
| STANDARD | WERKSTOFF NR. | UNS | GOST | AFNOR | JIS | OR | EN |
| Hastelloy C22 | 2.4602 | N06022 | – | – | NW 6022 | – | NiCr21Mo14W |
| ALLOY C-22 (Ni/22Cr/13Mo/3Fe/3W) / INCONEL 622/C-22 Round Bar | Dimension |
|---|---|
| cold drawn, solution annealed | Dia=16.0 mm, Weight=1.75 kg/m |
| hot worked, solution annealed, peeled | Dia=20.0 mm, Weight=2.6 kg/m |
| hot worked, solution annealed, peeled | Dia=25.4 mm, Weight=4.5 kg/m |
| hot worked, solution annealed, peeled | Dia=30.0 mm, Weight=6.14 kg/m |
| hot worked, sol annealed, peeled | Dia=38.1 mm, Weight=10.1 kg/m |
| extruded, machined, solution annealed | Dia=45.0 mm, Weight=13.15 kg/m |
| hot worked, solution annealed, peeled | Dia=50.8 mm, Weight=18.0 kg/m |
| extruded, machined, solution annealed | Dia=70.0 mm, Weight=35.0 kg/m |
| solution annealed, peeled | Dia=82.55 mm, Weight=47.6 kg/m |
| hot worked, solution annealed, peeled | Dia=101.6 mm, Weight=72.1 kg/m |
| forged, solution annealed, peeled | Dia=115.0 mm, Weight=89.4 kg/m |
| forged, solution annealed, peeled | Dia=130.0 mm, Weight=113.9 kg/m |
| forged, solution annealed, peeled | Dia=150.0 mm, Weight=152.15 kg/m |
| forged, turned | Dia=165.1 mm, Weight=187 kg/m |
Yes, Hastelloy C22 Bars are highly corrosion-resistant, particularly against pitting, crevice corrosion, and stress corrosion cracking in harsh environments. They excel in resisting acids, oxidizing agents, and chloride-induced corrosion.
Yes, Hastelloy C22 rods can be customized in size and length to meet specific industrial requirements. Manufacturers often offer tailored dimensions to suit diverse applications.
Hastelloy C22 bars perform exceptionally well in high-temperature environments due to their superior resistance to oxidation and thermal stability. They maintain strength and corrosion resistance under extreme conditions.
Hastelloy C22 Bars and Rods find extensive usage in industries demanding high corrosion resistance in highly aggressive environments. They are used in various chemical processing equipment such as heat exchangers, pressure vessels, reactors, pumps, and piping systems exposed to strong chlorides and acids. Their resistance to stress corrosion cracking and localized attack also makes Hastelloy C22 appropriate for pollution control equipment, marine uses, and petrochemical operations. Apart from these, Hastelloy C22 is used in aerospace parts and production of high-temperature alloys, where stability, durability, and safety over the long run are essential. Its superior properties make it a material of choice for high-performance, critical applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
