Aiman Metals, a Kuala Lumpur, Malaysia-based manufacturer and supplier of high-quality stainless steel products for various industrial uses, specializes in precision, long-lasting, and innovative solutions. Some of its high-performing solutions include Stainless Steel 15-5 PH Hex Bars and Rods, which are renowned for their high strength, corrosion resistance, and durability, and are utilized extensively in the aerospace, marine, and engineering industries. Our dedication to excellence guarantees that every product exceeds or meets the highest quality standards. Through offering customized solutions, Aiman Metals is serving a wide range of customers in Malaysia and across the globe, providing reliability for challenging and crucial applications.
Stainless Steel 15-5 PH Hex Bars and Rods are martensitic precipitation-hardening alloys that have a composition of about 15% chromium, 4–5% nickel, and 3–5% copper, with 0.05% carbon, 0.15–0.45% manganese, and trace silicon, phosphorus, and sulfur. Such a composition provides excellent strength, toughness, and corrosion resistance. In the condition H900, these bars reach tensile strengths ranging from 930–1170 MPa, yield strength of 865 MPa, and elongation of 14–16%. With a 38–42 HRC hardness range, SS 15-5 PH provides superior mechanical stability and is well-suited for challenging environments like aerospace, marine, and high-performance industrial applications.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Grade | C | Cb+Ta | Cr | Cu | Fe | Mn | Ni | P | S | Si |
| SS 15-5 PH | 0.07 max | 0.15-0.45 max | 14.0-15.0 max | 2.5-4.5 max | Bal | 1.0 | 3.5-5.5 | 0.04 | 0.03 | 1.0 |
| Grade | Tensile Strength ksi (MPa) | Yield Strength 0.2% ksi (min) | Elongation % | Hardness (Rockwell) MAX |
| SS 15-5 PH | 161,000 | 140,000 | 7.6% | C35 |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 15-5PH | 1.4545 | S15500 |
| HEXAGONS | ||
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Store Stainless Steel 15-5 PH hex bars and rods in a clean, dry, ventilated area, elevated on racks, with protective covers, separated from other metals, and handled carefully.
Stainless Steel 15-5 PH hex bars excel in wear-resistant applications due to their high strength, toughness, excellent corrosion resistance, and ability to maintain hardness after precipitation-hardening heat treatment.
Common challenges with Stainless Steel 15-5 PH hex bars include susceptibility to stress corrosion cracking in chloride environments, limited ductility in hardened conditions, higher machining difficulty, and potential distortion during heat treatment.
SS 15-5 PH Hex Bars and Rods find wide applications in industries where strength, corrosion resistance, and longevity are of concern. Typical aerospace applications include shafts, gears, and structural parts. In marine engineering, they are utilized for fittings and hardware resistant to stress corrosion cracking. They are also utilized in medical equipment, chemical processing plant equipment, and high-performance valves. In auto engineering, the bars find their best application in precision parts like drive shafts and transmission parts. Their support for stability withstanding heavy loads and adverse environmental conditions provides consistent performance in key applications across several industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
