Aiman Metals is a well-respected manufacturer and supplier located in Kuala Lumpur, Malaysia, known for its top-notch stainless steel products. With a strong focus on quality and customer satisfaction, Aiman Metals provides a diverse array of metal solutions, including Stainless Steel 17-4 PH Hex Bars and Rods. These products are celebrated for their precision engineering, durability, and resistance to corrosion, meeting the high standards required by various industries. Whether it’s for aerospace, marine, or industrial applications, Aiman Metals guarantees premium materials and prompt delivery, making it a reliable partner for all stainless steel needs in Malaysia and beyond.
Stainless Steel 17-4 PH is a precipitation-hardening martensitic stainless steel that contains about 17% chromium, 4% nickel, 3–5% copper, along with trace amounts of manganese, silicon, and niobium. It boasts impressive strength, hardness, and corrosion resistance, particularly when hardened. Typical mechanical properties include a tensile strength of up to 1100 MPa, a yield strength around 1000 MPa, and hardness reaching up to 44 HRC, depending on the heat treatment process. This alloy strikes a balance between excellent mechanical performance and moderate corrosion resistance, making it ideal for demanding structural and engineering applications.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Grade | C | Cb+Ta | Cr | Cu | Fe | Mn | Ni | P | S | Si |
| SS 17-4 PH | 0.07 max | 0.15-0.45 max | 15.00-17.50 max | 3.00-5.00 max | Bal | 1.0 | 3.0-5.0 | 0.40 | 0.03 | 1.0 |
| Grade | Tensile Strength ksi (MPa) | Yield Strength 0.2% ksi (min) | Elongation % | Hardness (Rockwell) MAX |
| SS 17-4 PH | 170000 psi | 140000 psi | 6% | 38 |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 17-4 PH | 1.4542 | S17400 |
| HEXAGONS | ||
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Stainless Steel 17-4 PH Hex Bars and Rods find extensive use in areas that require high strength, moderate corrosion resistance, and outstanding mechanical properties. They are commonly utilized in the aerospace industry for structural components, fasteners, and engine parts; in oil and gas for valves and pump shafts; and in marine applications due to their resistance to saltwater corrosion. Additionally, these bars and rods are used in medical devices, chemical processing equipment, and machinery in the food industry. The alloy’s adaptability in heat treatment further enhances its appeal across various sectors.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Aiman Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Kuala lumpur, Malaysia
