Aiman Metals, a Kuala Lumpur-headquartered company in Malaysia, specializes in the production and supply of Stainless Steel 304 Bars and Rods. Relying on their strength, durability, and resistance to corrosion, our SS 304 bars and rods are used by industries like structural engineering, automotive, and food processing. With a mission to provide precise engineered stainless steel solutions for individual project needs, we deliver high-quality products. Strongly emphasizing quality, timely supply, and competitive prices, Aiman Metals has established a reputation as a trustworthy partner for companies requiring high-performance stainless steel products. Our SS 304 rods and bars provide consistent performance in various applications.
Stainless Steel 304 Bars and Rods consist of 18–20% chromium for resistance to corrosion, 8–10.5% nickel for increased strength and durability, and up to 0.08% carbon to preserve weldability. Other constituents are up to 2% manganese, 0.045% phosphorus, and 0.03% sulfur, with iron making up the rest. In mechanical terms, SS 304 has a tensile strength of 515 MPa, yield strength of 205 MPa, and elongation of 40% on 50 mm, with a hardness of 92 HRB. All these characteristics make it perfect for use in applications that require both mechanical strength and high resistance to oxidation and corrosion.
| Specification | ASTM A479/ SA479 ASTM A276/ ASME SA276 |
|---|---|
| Grade | Stainless Steel 304 (UNS S30400) |
| Hex Bar size | 18 to 57mm (11/16″ – 2-3/4″) |
| Round bar size | OD 4mm to 500mm |
| Square bar size | 18mm to 47mm (11/16″- 1-3/4″) |
| Billet Size | 1/2″- 495mm Dia. |
| Rectangles Size | 33 x 30mm – 295 x 1066mm |
| Bright Bar | OD 4mm to 100mm |
| Tolerance | K12 H12, K10, H9, H11, H8, H13K9, H10, K11, or as per need |
| Flat bar size | 1/2” to 10” in thickness of 2 to 150mm |
| Angle bar size | 3*20*20~12*100*100 |
| Finish | centreless ground, Cold (bright) drawn, hot rolled, peeled, smooth turned, hot rolled annealed, slit rolled edge, Bright, Rough Turned, Grinding, Polish & Black |
| Form | Flat Bar, Hollow, Round, Square, Triangle, Rectangle, Half Round Bar, Rod, T-Bar, Precision Ground Bar, Hex (A/F), Blocks, Channel Bar, Threaded, Round Rod, Billet, Profiles, I/H Bar, Ingot, Rings, Forging etc. |
| Technique | 440C Stainless Steel Hot Rolled, Cold Drawn, Rod, Forged Round Bar, Cold Rolled |
| Condition | annealed, Hardened & tempered |
| Section | 3.0 -12.0 mm thickness, 80 x 40 to 150 x 75mm section |
| Channel Bar | 5.0 – 6.0mm thickness |
| Surface | Bright, Cold Drawn, Hot Rolled Pickled, Sand Blasting Finished, Polished, Hairline |
| Hollow Bar | 32mm OD x 16mm ID – 250mm OD x 200mm ID |
| Grade | Mn | C | Si | S | P | Cr | Ni | Mo | N |
| SS 304 | 2 maximum | 0.08 maximum | 0.75 maximum | 0.030 maximum | 0.040 maximum | 18 – 20 | 8 – 11 | – | – |
| Density | Elongation | Tensile Strength | Melting Point | (0.2%Offset) Yield Strength |
| 8.0 g/cm3 | 35 % | MPa – 515 , Psi – 75000 | 1400 °C (2550 °F) | MPa – 205, Psi – 30000 |
|
Type |
SIZES (Inches) |
ISO Tolerance |
SIZES (mm) |
|---|---|---|---|
|
Peeled and Polished |
1.50″ to 6.00″ |
h11-DIN 1013 |
40.00 to 150.00 |
|
Cold Drawn and Ground |
5/6″ to 2.50″ |
h9-h8-h11-h10 |
10.00 to 75.00 |
|
Cold Drawn and Polish |
1/8″ to 3.00″ |
h9-h8-h11-h10 |
3.00 to 75.00 |
|
Peeled and Ground |
3/4″ to 2.00″ |
h10-h9-h11 |
20.00 to 50.00 |
|
STANDARD |
UNS |
WERKSTOFF NR. |
BS |
JIS |
AFNOR |
GOST |
EN |
|
SS 304 |
S30400 |
1.4301 |
304S31 |
SUS 304 |
Z7CN18‐09 |
08Х18Н10 |
X5CrNi18-10 |
Stainless Steel 304 Bars and Rods offer excellent corrosion resistance, high tensile strength, and good machinability. They are also highly resistant to oxidation and can withstand various industrial and environmental conditions, making them suitable for a wide range of applications.
Stainless Steel 304 Bars and Rods are widely used in industries such as food processing, automotive, chemical, pharmaceutical, and construction. They are used for manufacturing parts like shafts, fasteners, pipes, and structural components due to their durability and corrosion resistance.
Yes, Stainless Steel 304 Bars and Rods perform well in high-temperature environments, with the ability to withstand temperatures up to 870°C (1600°F) in intermittent service. This makes them suitable for applications in heat exchangers, ovens, and other high-heat environments.
Stainless Steel 304 Bars and Rods find extensive application in industries that need strength, corrosion resistance, and versatility in combination. They are employed for shafts, bolts, fasteners, and equipment parts in manufacturing. The food processing sector appreciates SS 304 for kitchen appliances, equipment, and storage tanks because of its hygienic and corrosion-free properties. In the pharmaceutical industry, it is used for equipment and piping systems. At a structural level, SS 304 is utilized for railings, pipes, and architectural fittings. It is also applied in the automotive industry, chemical processing equipment, and heat exchangers. Its versatility causes SS 304 to be a preferred option for various industrial and commercial uses.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Aiman Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Kuala lumpur, Malaysia
