Aiman Metals stands out as a premier manufacturer and supplier of top-notch stainless steel products, proudly based in Kuala Lumpur, Malaysia. We focus on crafting Stainless Steel 304H Bars and Rods, which are celebrated for their remarkable strength and durability, especially at high temperatures. As a reputable name in the metal industry, Aiman Metals caters to a variety of sectors, including chemical processing, oil and gas, and power generation. Our products meet international quality standards, guaranteeing consistent performance, corrosion resistance, and structural integrity. With a strong commitment to excellence and timely delivery, Aiman Metals is your go-to partner for high-quality stainless steel solutions throughout Malaysia.
Stainless Steel 304H is a high-carbon version of the 304 grade, featuring about 18–20% chromium and 8–11% nickel, along with a higher carbon content (0.04–0.10%) that boosts strength at elevated temperatures. It boasts impressive resistance to oxidation and corrosion, with a tensile strength of around 585 MPa and a yield strength of 240 MPa. This alloy also offers good weldability and formability. The increased carbon content enhances creep resistance, making it perfect for high-temperature applications where mechanical stress and thermal fatigue are common, particularly in pressure vessels and heat exchanger systems.
| Grade | Stainless Steel 304H (UNS S30409) |
|---|---|
| Specification | ASTM A276, ASTM A479 |
| Round bar size | Diameter: 3-~800mm |
| Hex Bar size | 2-100mm A/F |
| Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Hollow Bar | 32 OD x 16 ID to 250 OD x 200 ID |
| Square bar size | 4 to 100mm |
| Section | 3.0 to 12.0mm thickness |
| Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Billet Size | 1/2″ to 495mm Diameter |
| Channel Bar | 80 x 40 to 150 x 75 mm section; 5 to 6 mm thickness |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Angle bar size | 3*20*2~12*100*100 mm |
| Form | Rings, Profiles, Hollow, Flat Bar, Square, Round, Rectangle, Triangle, Rod, Half Round Bar, T-Bar, Hex (A/F), Precision Ground Bar, Channel Bar, Blocks, Round Rod, Threaded, Billet, Ingot, I/H Bar, Forging etc. |
| Technique | Cold Drawn, Rod, Hot Rolled, Cold Rolled, Forged Round Bar |
| Condition | annealed, Hardened & tempered |
| Surface | Cold Drawn, Polished, Bright, Hot Rolled Pickled, Sand Blasting Finished,Hairline |
| Element | SS 304H |
| C | 0.10 max |
| Ni | 8.0 – 10.5 |
| P | 0.045 max. |
| Mn | 2.00 max |
| Si | 0.75 max |
| S | 0.03 max. |
| Cr | 18.0 – 20.0 |
| Element | SS 304H |
| Melting Point | 1400 ℃ |
| Density | 8 |
| Hardness (Brinell) | 201 |
| Yield Strength (0.2%Offset) | 205 |
| Tensile Strength | 515 |
| Elongation | 40 |
|
Type |
SIZES (Inches) |
ISO Tolerance |
SIZES (mm) |
|---|---|---|---|
|
Peeled and Polished |
1.50″ to 6.00″ |
h11-DIN 1013 |
40.00 to 150.00 |
|
Cold Drawn and Ground |
5/6″ to 2.50″ |
h9-h8-h11-h10 |
10.00 to 75.00 |
|
Cold Drawn and Polish |
1/8″ to 3.00″ |
h9-h8-h11-h10 |
3.00 to 75.00 |
|
Peeled and Ground |
3/4″ to 2.00″ |
h10-h9-h11 |
20.00 to 50.00 |
| STANDARD | UNS | WERKSTOFF NR. |
| SS 304H | S30409 | 1.4301 |
Stainless Steel 304H Bars and Rods find extensive use in high-temperature and high-pressure settings due to their superior mechanical strength and corrosion resistance. They are commonly utilized in superheater and reheater tubes in boilers, heat exchangers, pressure vessels, and chemical processing equipment. Additionally, these materials are essential in refineries, nuclear power plants, and thermal power stations, where resistance to thermal fatigue and scaling is crucial. Thanks to their excellent weldability and formability, these bars and rods are perfect for creating components that frequently undergo thermal cycling.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
