Aiman Metals stands out as a top-notch manufacturer and supplier located in Kuala Lumpur, Malaysia, with a focus on high-quality stainless steel products. We take pride in our dedication to excellence, offering a diverse selection of stainless steel materials, including our top-performing Stainless Steel 310 Square Bars and Rods. Built for durability and reliability, our Stainless Steel 310 products adhere to both national and international quality standards. With a solid foothold in both the Malaysian and global markets, Aiman Metals is committed to providing exceptional metal solutions tailored to various industrial needs, such as construction, manufacturing, petrochemical, and thermal processing sectors.
Stainless Steel 310 Square Bars and Rods are mainly made up of chromium (24-26%) and nickel (19-22%), which give them outstanding oxidation and corrosion resistance. They also contain manganese, silicon, and a low carbon content, which boosts their structural integrity. These bars have a tensile strength of around 515 MPa and a yield strength of 205 MPa, along with a good elongation rate of 40%. The material retains its strength and toughness even in high-temperature settings, making it perfect for demanding environments. Its austenitic structure provides excellent ductility, formability, and weldability, which are crucial for various industrial applications.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A582, A276, A564, ASTM A484, 484M
Surface : hrap, hot rolled pickled or sand blasting finished, cold drawn, polished, hairline
Size : Tolerance: H8, H9, H10, H11, H12, H13K9, K10, K11, K12
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 310 | 0.25 max | 24.0 – 26.0 | 2.00 max | 19.0 – 22.0 | 0.045 max. | 0.03 max. | 1.50 max. |
| Element | Density | Melting Range,℃ | Tensile Strength | Yield Strength | Elongation | Hardness (Brinell) |
| SS 310 | 8 | 1400 ℃ | 515 MPa | 205 | 40 | 217 |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 310 | 1.4841 | S31000 |
| SQUARES | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.62 | 2.05 |
| 18 | 0.79 | 2.59 |
| 20 | 0.76 | 2.49 |
| 22 | 1.18 | 3.87 |
| 25 | 1.52 | 5.00 |
| 28 | 1.91 | 6.27 |
| 30 | 2.19 | 7.20 |
| 32 | 2.50 | 8.19 |
| 36 | 3.16 | 10.37 |
| 38 | 3.52 | 11.55 |
| 40 | 3.90 | 12.80 |
| 45 | 4.94 | 16.20 |
| 50 | 6.10 | 20.00 |
| 56 | 7.65 | 25.08 |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Stainless Steel 310 Square Bars and Rods are widely utilized in high-temperature and corrosive settings thanks to their remarkable heat resistance and mechanical strength. You’ll often find them in heat exchangers, furnace components, combustion chambers, and thermal processing equipment. In the chemical and petrochemical sectors, they serve as structural supports and piping systems for high-temperature fluids. Additionally, these bars are used in power plants, cement plants, and marine environments. Their durability, resistance to scaling, and ability to perform under extreme conditions make them a reliable choice for many applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Aiman Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Kuala lumpur, Malaysia
