We take pride in being a top manufacturer and supplier of Stainless Steel 347H Hex Bars, providing high-quality products designed for outstanding performance in both high-temperature and corrosive settings. Grade 347H is a high-carbon austenitic stainless steel that’s stabilized with niobium (columbium) to boost its resistance to intergranular corrosion. Our SS 347H hex bars are meticulously crafted to meet tight dimensional tolerances, deliver an excellent surface finish, and offer superior mechanical properties. They’re particularly ideal for applications that involve continuous exposure to elevated temperatures, showcasing impressive creep strength and oxidation resistance. You’ll find Stainless Steel 347H hex bars commonly used in heat exchangers, boiler tubes, pressure vessels, and chemical processing equipment.
Stainless Steel 347H Hex Bars generally consist of 17–19% Chromium, 9–13% Nickel, 0.04–0.10% Carbon, and niobium for stabilization, along with trace amounts of Manganese, Silicon, and Phosphorus. The higher carbon content in 347H enhances its creep resistance and high-temperature strength. Mechanical properties include a tensile strength of about 515 MPa, yield strength of 205 MPa, and impressive elongation of around 35%. This alloy retains good toughness even at cryogenic temperatures and resists oxidation up to 870°C. The niobium content helps prevent carbide precipitation during welding, ensuring reliability for long-term use in high-heat environments.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 347h | 0.08 max. | 17.0 – 19.0 | 2.00 max. | 9.0-13.0 | 0.045 max. | 0.03 max. | 0.75 max |
| Element | Density | Melting Range,℃ | Tensile Strength | Yield Strength | Elongation | Hardness (Brinell) |
| SS 347h | 7.96 | 1450 ℃ | 515 | 205 | 40 | 201 |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Stainless Steel 347H Hex Bars are widely utilized in industries where components are subjected to prolonged high temperatures and corrosive conditions. You’ll often find them in applications like furnace parts, heat exchangers, superheater tubes, boiler equipment, and high-temperature gaskets. In the chemical processing industry, 347H is the go-to choice for equipment that deals with hot acids, alkalis, and other aggressive chemicals. Its excellent welding characteristics make it perfect for fabricating pressure vessels and piping systems, ensuring durability and performance in demanding environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
