Aiman Metals is a trusted and seasoned manufacturer and supplier of stainless steel products, proudly based in Kuala Lumpur, Malaysia. We offer a diverse range of items, including Stainless Steel 430 Square Bars and Rods. Renowned for our commitment to quality, precision, and customer-focused service, Aiman Metals delivers cost-effective stainless steel solutions suitable for various industrial and structural needs. Our Stainless Steel 430 Square Bars and Rods are crafted using cutting-edge techniques to guarantee consistent performance, corrosion resistance, and precise dimensions. With a clientele spanning Malaysia and beyond, we are dedicated to providing durable materials at competitive prices, along with prompt and professional support.
Stainless Steel 430 is a ferritic stainless steel alloy that mainly consists of 16–18% chromium and low carbon (≤0.12%), along with small amounts of manganese, silicon, and nickel. It boasts moderate corrosion resistance, especially in mildly acidic and oxidizing conditions, and offers good formability. In terms of mechanical properties, it has a tensile strength ranging from about 450 to 600 MPa and a yield strength of around 250 MPa. This alloy is magnetic and cannot be hardened through heat treatment, but it can be strengthened by cold working. SS 430 retains solid structural integrity and oxidation resistance at moderate temperatures.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A582, A276, A564, ASTM A484, 484M
Surface : hrap, hot rolled pickled or sand blasting finished, cold drawn, polished, hairline
Size : Tolerance: H8, H9, H10, H11, H12, H13K9, K10, K11, K12
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 430 | 0.12 | 18.0 | 1.25 | – | 0.06 | 0.15 | 1.00 |
| Element | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness (Brinell (HB) max) |
| SS 430 | 552 | 379 | 25 | 262 |
| STANDARD | WERKSTOFF NR. | UNS | JIS |
| SS 430 | 1.4104 | S43020 | SUS 430 |
| SQUARES | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.62 | 2.05 |
| 18 | 0.79 | 2.59 |
| 20 | 0.76 | 2.49 |
| 22 | 1.18 | 3.87 |
| 25 | 1.52 | 5.00 |
| 28 | 1.91 | 6.27 |
| 30 | 2.19 | 7.20 |
| 32 | 2.50 | 8.19 |
| 36 | 3.16 | 10.37 |
| 38 | 3.52 | 11.55 |
| 40 | 3.90 | 12.80 |
| 45 | 4.94 | 16.20 |
| 50 | 6.10 | 20.00 |
| 56 | 7.65 | 25.08 |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Stainless Steel 430 Square Bars and Rods find extensive use in applications that demand good corrosion resistance, formability, and structural strength without breaking the bank. You’ll often see them in kitchen equipment, architectural trim, automotive parts, appliance components, and fasteners. In industrial settings, they’re perfect for conveyor systems, storage racks, and frameworks that face moderate corrosion. The square shape offers strength and even load distribution, making them ideal for fabrication, structural supports, and brackets. Plus, their excellent machinability makes them a go-to choice for many projects
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
