Aiman Metals, located in Kuala Lumpur, Malaysia, stands out as a top manufacturer and supplier of high-quality Super Duplex Steel S32760 Forgings. Known for their commitment to providing durable and reliable metal solutions, Aiman Metals serves a variety of heavy-duty industries that demand exceptional strength and corrosion resistance. The company employs cutting-edge forging techniques and follows international quality standards to create components that excel in extreme conditions. Their Super Duplex S32760 forgings are designed for precision, toughness, and long-lasting durability, making Aiman Metals a trusted ally for clients in the oil and gas, marine, chemical, and power generation sectors, both in Malaysia and beyond.
Super Duplex Steel S32760 Forgings are made up of around 25% chromium, 7% nickel, and 3.5% molybdenum, along with some tungsten, nitrogen, and low carbon content. This unique composition results in a robust duplex microstructure of ferrite and austenite, providing outstanding resistance to chloride-induced stress corrosion cracking, pitting, and crevice corrosion. On the mechanical side, the alloy boasts a tensile strength of 750–800 MPa, a yield strength of about 550 MPa, and impressive impact toughness, even in low temperatures. With a high PREN (>40), it ensures excellent performance in seawater and aggressive chemical environments, making it perfect for demanding industrial forgings.
| Standard | ASTM A182, ASME SA182 |
| Specification | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs. |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs. |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs. |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S32760 | 0.05 max | 1.00 max | 1.00 max | 0.030 max | 0.010 max | 24.00 – 26.00 | 3.00 – 4.00 | 6.00 – 8.00 | 0.20 – 0.30 | 57.61 min |
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| S32760 | 7.8 | 0.281 | 1350 | 2460 |
| STANDARD | WERKSTOFF NR. | UNS |
| Super Duplex S32760 | 1.4501 | S32760 |
Super Duplex Steel S32760 Forgings find their place in critical applications where mechanical strength and corrosion resistance are paramount. They are particularly suited for offshore oil and gas platforms, subsea components, pressure vessels, flanges, pump parts, and valve bodies. Additionally, these forgings are utilized in desalination plants, marine hardware, chemical processing systems, and structural components that face harsh environments. Their capability to endure high pressure, temperature, and corrosive agents makes them ideal for power generation applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
