Aiman Metals is a reliable manufacturer and supplier of Titanium Grade 7 forgings, proudly based in Kuala Lumpur, Malaysia. We focus on providing top-notch titanium products that adhere to international standards for strength, durability, and corrosion resistance. Titanium Grade 7 is especially prized for its exceptional resistance to corrosion, making it perfect for demanding environments. With state-of-the-art manufacturing facilities and a dedication to precision engineering, Aiman Metals serves various industries, including chemical processing, marine, and power generation. Our commitment to quality, competitive pricing, and customer satisfaction has made us a go-to partner for Titanium Grade 7 forging solutions, both in Malaysia and around the world.
Titanium Grade 7 (Ti-0.2Pd) is a corrosion-resistant alloy made up of titanium with about 0.12–0.25% palladium. Its mechanical properties are quite similar to those of Grade 2 titanium, boasting a tensile strength of around 344 MPa and a yield strength of 275 MPa, along with excellent ductility and weldability. The inclusion of palladium significantly boosts its resistance to crevice and reducing acid corrosion, especially in chloride and acidic settings. Titanium Grade 7 forgings are perfect for ensuring long-term reliability in harsh chemical and seawater conditions, maintaining mechanical stability across various temperatures and pressures.
| Specifications | ASTM B381, ASME SB381 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | N | O | H | Ti | Fe | Al | Pd |
| Titanium Gr 7 | 08 max | 03 max | 25 max | 015 max | Bal | 0.30 max | – | .12 – .25 |
| 0.2% Proof Stress MPa | Tensile Strength MPa | Elongation % |
| 275-475 | 345 | 20 |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 7 | 3.7235 | R52400 |
Titanium Grade 7 forgings find extensive use in industries that demand outstanding corrosion resistance, particularly in reducing acid environments. In the chemical processing sector, they are utilized in heat exchangers, reactor vessels, and piping systems that handle aggressive acids like hydrochloric and sulfuric acid. The marine industry benefits from its durability in saltwater, making it ideal for underwater and offshore components. Additionally, it is employed in power generation plants for condenser tubing and other corrosive systems. Thanks to its biocompatibility, it is also a popular choice in medical applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Aiman Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Kuala lumpur, Malaysia
