Aiman Metals, located in Kuala Lumpur, Malaysia, has built a solid reputation as a top-notch manufacturer and supplier of high-quality Titanium Round Bars, serving both local and global markets. With a keen emphasis on quality, precision, and performance, Aiman Metals provides titanium round bars that meet international standards like ASTM and AMS. These bars are celebrated for their impressive strength-to-weight ratio, resistance to corrosion, and long-lasting durability, making them perfect for critical industrial applications. Supported by cutting-edge technology and a committed team, Aiman Metals guarantees timely deliveries and customized solutions to adapt to the changing demands of various high-performance industries.
Titanium Round Bars are typically made from commercially pure grades (such as Grade 2) or titanium alloys like Grade 5 (Ti-6Al-4V). Depending on the grade, they usually include elements like aluminum, vanadium, iron, and oxygen. Their mechanical properties showcase tensile strength ranging from 345 MPa (Grade 2) to 900 MPa (Grade 5), along with outstanding corrosion resistance and a low density of 4.51 g/cm³. These titanium bars are known for their good weldability, fatigue resistance, and biocompatibility. With a high melting point of around 1660°C and the ability to maintain strength at elevated temperatures, they are well-suited for demanding engineering and medical applications.
| Grade | Gr 1, Gr 2, Gr 3, Gr 4, Gr 5, Gr 7, Gr 9, Gr 12, Gr 23, TA1-TA4, TA7-TA10, TA15-TA18, GR1-GR5, GR6,GR7, GR9, GR11, GR12, TI-6AL-4V, TI-6AL-4VELI,GR23 | |||||
| Sizes | Minimum diameter: 0.040 inch or 1.00 mm Maximum diameter: 14.000 inch or 400.00 mm | |||||
| Standard | ASTM F136, ASTM B348, ASTM F136, ASTM F67, AMS4928, ISO-5832-2(3), MIL-T-9047G, JIS etc | |||||
| Type | Ti square bar, Ti round bar, Ti hexagonal bar, Ti flat bar, Titanium Alloy Bars, Ti Billets, Forgings, and Forging Stock | |||||
| Condition | R/M /Y | |||||
| AMS Specificaton of Titanium Round Bar | AMS-T-9047 (6AL-6V-2SN), AMS-T-9047 (CP-70 GR.4), ASTM B348 (Grade 5), ASTM B348 (Grade 2), ASTM B348 (Grade 4), ASTM B348 (Grade 23), ASTM F67 (Grade 2), ASTM F67 (Grade 4), ASTM F136, ASTM F1472, MIL-T-9047 (6AL-4V), MIL-T-9047 (6AL-4V ELI), MIL-T-9047 (6AL-6V-2SN), MIL-T-9047 (CP-70 GR.4), DMS 1570, DMS 1583, AMS 4971, AMS 4921, AMS 4928, AMS 4930, AMS 4965, AMS 4967, AMS 4978, AMS 4979, AMS 6930, AMS 6931, AMS 6935, AMS 6936, AMS-T-9047 (6AL-4V), AMS-T-9047 (6AL-4V ELI) and More. | |||||
| Titanium Round Bar Uses |
|
|||||
| Titanium Round Bar Order & Packing Information | ||||||
| Min. Order: 10 Pieces (or please enquire for your customized order) Trade Terms: FOB, CIF Payment Terms: L/C, T/T Packing: as per requirement Place of Origin: Mumbai, India Means of Transport: Land, Ocean Delivery Date: one or two week Package: in wooden crate with plastic caps on each end. | ||||||
| Titanium Alloy Round Bar Grades | Commercially Pure Titanium and Titanium Alloys: 6Al-4V ELI | 6Al-4V | 6Al-6V-2SN | 6Al-2SN-4ZR-6MO | 7Al-4Mo Grade 1 | Grade 2 | Grade 4 | Grade 17 | |||||
|
Hardness, Brinell |
120 |
120 |
annealed |
|
Hardness, Knoop |
132 |
132 |
Estimated from Brinell. |
|
Hardness, Rockwell B |
70 |
70 |
annealed |
|
Hardness, Vickers |
122 |
122 |
Estimated from Brinell |
|
Tensile Strength, Ultimate |
240 MPa |
34800 psi |
– |
|
Tensile Strength, Yield |
170 – 310 MPa |
24700 – 45000 psi |
– |
|
Elongation at Break |
24 % |
24 % |
– |
|
Reduction of Area |
35 % |
35 % |
– |
|
Modulus of Elasticity |
105 GPa |
15200 ksi |
In Tension |
|
Compressive Modulus |
110 GPa |
16000 ksi |
– |
|
Poisson’s Ratio |
0.37 |
0.37 |
– |
|
Charpy Impact |
310 J |
229 ft-lb |
V-notch |
|
Shear Modulus |
45 GPa |
6530 ksi |
– |
|
Physical Properties |
Metric |
English |
|
Density |
4.51 g/cc |
0.163 lb/in³ |
| Physical Properties | Metric | English |
|---|---|---|
| Density | 4.51 g/cc | 0.163 lb/in³ |
|
STANDARD |
WERKSTOFF NR. |
UNS |
|
Titanium |
3.7035 / 3.7165 / 3.7235 |
R50400 / R56400 / R52400 |
Type | SIZES (mm) | SIZES (Inches) | ISO Tolerance |
|---|---|---|---|
Cold Drawn and Polish | 3.00 – 75.00 | 1/8 – 3.00 | h8-h9-h10-h11 |
Cold Drawn and Ground | 10.00 – 75.00 | 5/6 – 2.50 | h8-h9-h10-h11 |
Peeled and Polished | 40.00 – 150.00 | 1.50 – 6.00 | h11, h11-DIN 1013 |
Peeled and Ground | 20.00 – 50.00 | 3/4 – 2.00 | h9-h10-h11 |
Titanium Alloy Bars Standard lengths of 2010 mm up to 200 mm. Cut to size on request (tolerance +2/-0 mm).
5.0 | 45.0 |
6.0 | 50.0 |
7.0 | 55.0 |
8.0 | 60.0 |
9.0 | 65.0 |
10.0 | 70.0 |
12.0 | 75.0 |
16.0 | 80.0 |
20.0 | 90.0 |
25.0 | 100.0 |
30.0 | 130.0 |
35.0 | 160.0 |
40.0 | 201.0 |
Titanium Round Bars find extensive use in industries that require lightweight and corrosion-resistant materials. In aerospace, they are utilized for components like aircraft parts, landing gear, and engine components. The medical field employs titanium bars for surgical implants, orthopedic rods, and dental devices, thanks to their biocompatibility. In marine and offshore applications, they are prized for their resistance to seawater corrosion. Additionally, titanium bars are used in chemical processing, power generation, automotive, and sports equipment manufacturing. Their strength, durability, and non-magnetic properties make them a go-to choice across various sectors.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Aiman Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Kuala lumpur, Malaysia
